LACP link aggregation is a popular and highly effective way for organizations to manage and improve their networks. This is not just from an operational efficiency perspective, but also from a security viewpoint. This article will serve as a simple guide to LACP link aggregation, and provide insights into how it works, a step-by-step guide to setup, and why it’s crucial in enhancing the reliability and efficiency of a network.
What is LACP Link Aggregation?
Link Aggregation Control Protocol (LACP) is an IEEE 802.3ad standard for maintaining and negotiating Link Aggregation Groups (LAGs).
A LAG is the resulting single logical link that is created once the various links have been aggregated. LACP then consists of the automatic management of these links, with there also being an option of static link aggregation, which we will look into in more detail.
How LACP Works: Simplified Overview
There are a few key elements of LACP to bear in mind when understanding how LACP works. Here’s a simplified overview:
- Negotiation between network devices to form an aggregated link
Devices that are LACP compatible will communicate with each other and share network details such as MAC addresses in order to establish a connection.
This is achieved by exchanging LACPDUs (Link Aggregation Control Protocol Data Units) either via an active or passive mode. In active mode, LACPDUs are sent to kickstart the connection, and in passive mode, a device will wait to receive LACPDUs and then respond accordingly.
Once an aggregated link is established, LACP will maintain the logical link via continuous monitoring, providing failover protection so there is no network disruption.
There are several ways in which LACP balances traffic, one of which is where every device in the LAG uses a hashing algorithm in order to select the particular link that a packet will be assigned to.
Per-flow distribution is another method where traffic is balanced and distributed by flow as opposed to bandwidth.
Why Link Aggregation Matters for Network Reliability
Network reliability can be greatly enhanced with LACP, and this is due to:
- Improved bandwidth and throughput
Improved bandwidth is one of the benefits that link aggregation provides and is possibly the most noticeable improvement. Network traffic is spread across the various aggregated links, resulting in reduced congestion and a higher throughput.
- Simplified management of multiple connections
As a single, logical link is created from multiple ports, management is dramatically improved, helping to increase operational efficiency and allows organizations to monitor the network more easily.
LACP vs. Static Link Aggregation: What’s the Difference?
Link aggregation can either be carried out manually (static) or dynamically (LACP). LACP uses protocol negotiation to automatically aggregate multiple physical links into one, logical link.
Both static and LACP link aggregation can be used to create a single logical link, there are some key differences between the two:
LACP is universally supported, as it is part of IEEE 802.3ad. Link aggregation takes place automatically, and automatic failover is a key benefit here.
Static link aggregation has a higher risk of errors and misconfiguration as it relies on manual configuration, and does not support automatic failover. This makes it less flexible and is best suited to basic network setups.
How to Configure LACP Link Aggregation (Step-by-Step)
Step 1: The first step in configuring LACP Link Aggregation is to ensure compatibility between devices, and that they both support LACP link aggregation.
Step 2: The port settings must then be matched so that the speed, in terms of data transfer rate, duplex mode, and MTU size are all in sync.
The duplex mode can either be full duplex, which allows data to be transmitted and received at the same time, thus improving performance, or, half duplex, only transmission or reception can occur at any given time.
MTU (Maximum Transmission Unit) size relates to the maximum packet size that can be sent in a network.
Step 3: Physically connect the devices together with the relevant cables
Step 4: Configure the first device by accessing the switch’s CLI (command line interface), then enter configuration mode using the command “configure terminal” on the CLI
Step 5: Create a link aggregation group (LAG)
Step 6: Configure each individual port required and add them to the LAG
Step 7: Save your configuration
To verify LACP status in Cisco, you can enter show commands such as “show lacp counters” to display LACP statistics, and “show lacp internal” to display the internal information of an LACP.
Troubleshooting Common LACP Issues
- Mismatched configurations between switches
One of the common LACP issues one may encounter is a native VLAN mismatch. In this scenario, one of the two switches (connected via a single trunk port) is configured with an alternative native VLAN.
To rectify this issue, the native VLAN must be checked to ensure that it is configured so that they are the same on both ends of the trunk link.
Often certain LACP issues are caused by simple wiring misconfigurations. Simply checking that the correct cables are connected to the corresponding port can resolve this issue.
Outdated firmware can also cause issues with LACP, and this could be in the form of bugs causing malfunctions. Therefore it is important not just to update firmware if there is an issue, but to keep up to date regardless, in order to keep things running as they should.
LACP and Network Security Considerations
- Managing MAC address consistency and spoofing prevention
Media Access Control (MAC) spoofing attacks consist of attackers impersonating a genuine device by changing the MAC address, with the goal of stealing sensitive information and gaining access to restricted devices.
These attacks can be prevented by constantly monitoring network traffic, and implementing like zero-trust access policies, and configuring network switches to limit how many MAC addresses are physically allowed on a single port.
- Combine security methods and conduct regular audits
Regularly reviewing MAC address configurations, and combining security methods such as MAC filtering and implementing Address Resolution Protocol (ARP) inspection can also help mitigate security risks.
Real-World Applications of LACP in Secure Networking
Here are some real world examples of how LACP in secure networking can be applied:
- High-availability setups for security devices (NVRs, servers, switches)
LACP increases redundancy and improves reliability, which includes automatic failovers if physical links fail. This provides continuous operation, which is crucial for organizations such as data centers, enterprise companies, and industries such as transportation and logistics.
- Security and surveillance systems
Video surveillance not only needs a high bandwidth, but a constant feed, and downtime is simply not an option. LACP is able to facilitate the high levels of throughput required so that video surveillance systems run as they should.
How Comnet Supports Reliable Network Infrastructure
Both our hardware and software solutions are designed and constantly being improved with network reliability in mind. From our solid ethernet switches to our excellent remote monitoring and network management solutions, we take care of every angle so our clients can focus on their business and daily operations.
We fully appreciate the need for high uptime and increased redundancy, and this is taken into consideration across our software and hardware so our customers are able to benefit from continuous operation.
Conclusion
LACP is an effective and reliable way for organizations to greatly benefit from increased bandwidth, higher security, and improved reliability across their networks. The ability to combine multiple network links into a single channel means that redundancy is also improved.
Although static link aggregation also can be used to create a single, logical link, the manual nature means that the risk of errors is increased and the flexibility and reliability is simply not there when compared to LACP.
